Position Limit Switch XLS-P54D-PP/NP
This crossed rods limit switch triggers a slowing of the machines before the stop. This smooth braking sensibly reduce the risk of crashing due to sudden halts. They are fitted with 4 microswitches .and It functions both clockwise and counter clockwise.Features
Designed to guarantee excellent performance in the most challenging operating conditions.
1.Rods with 4 maintained positions every 90° 4 fixing holes.
2.Positive opening NC contacts for safety functions.
3.Mechanical life of switches:
Model | XLS-P54D-PP/NP |
Case | Glass fiber reinforced,thermoplastic |
Actuator Type | Crossed Rods Lever |
movement of operating head | Rotary |
type of operator | Aluminium |
Fixing type | Stay put crossed rods lever metal (square rod 6 mm, L = 200 mm) |
type of approach | Lateral approach 2 directions |
number of poles | 4 |
contact operation | Slow-break, staggered |
Contact Type & Operation: | 2 x (2 NC) |
Product Range: | Limit Switches |
Cable entry: | cable clamp M20 |
Markings and homologations: | CE |
Conformity to Standards: | EN 60947-5-1 |
Rated insulation voltage: | 500 Vac |
Utilisation category: | AC 15 |
Rated operational voltage: | 250 Vac |
rated impulse withstand voltage | 6 kV |
- Parameters
Model | XLS-P54D-PP/NP |
Case | Glass fiber reinforced,thermoplastic |
Actuator Type | Crossed Rods Lever |
movement of operating head | Rotary |
type of operator | Aluminium |
Fixing type | Stay put crossed rods lever metal (square rod 6 mm, L = 200 mm) |
type of approach | Lateral approach 2 directions |
number of poles | 4 |
contact operation | Slow-break, staggered |
Contact Type & Operation: | 2 x (2 NC) |
Product Range: | Limit Switches |
Cable entry: | cable clamp M20 |
Markings and homologations: | CE |
Conformity to Standards: | EN 60947-5-1 |
Rated insulation voltage: | 500 Vac |
Utilisation category: | AC 15 |
Rated operational voltage: | 250 Vac |
rated impulse withstand voltage | 6 kV |
